Nguồn Chuẩn Thí Nghiệm ATZ97

Code: #ATZ97

1 electronic circuit design and debugging 2 industrial control, power measurement 3 visits transient signal 4 manufacturing test 5 Education and Training 6 Service Repair

Tình trạng sản phẩm

Còn hàng
  • chi tiết
  • Download

Nguồn Chuẩn Thí Nghiệm ATZ97

ATZ97 Series DC electronic load,as a new generatation product of ATTEN Electronical Co.Ltd is designed with high-performance chips,high speed,high accuracy and with resolution of 0.1Mv and 0.01mA(the basic accuracy is 0.03%,the basic current rise speed is 2.5A/us),ATZ97 series has a wide application in production line(call phone charger,cell phone battery,electric vehicle battery,Switching power supplier,linear power supplier)research institutes,automotice electronics,aeronautics and astronautics,ships,solar cells,fuel cell,etc.

ATZ97 series offers users with its novel design,rigorous process and attrative cost-effectiveness

Features

Six high speed operation molds:CC,CR,CV,CW,CC+CV,CR+CW

Over current,over voltage,over power,over heat,polarity reversed protection

High-luminance VFD screen with two lines&four channels display

Intellegent fan system fan will be automatically initiated according to the temperature

Soft start time setting,carrying the power supplier according to the voltage value set

Battery testing and short-circuit function

Available of dynamic testing and rising edge and falling edge setting

Supporting external trigger input and output

External current waveform monitor terminal

Supporting remote voltage compensation and multidata storage

Power-on-self-test,software calibration and standard rack mount

Communication mode:GPIB/RS232/RS485/USB

Technical specification table

Model

ATZ9711

ATZ9712

Input raiting

Power

150W

300W

Current

0-30A

0-30A

Voltage

0-150V

0-150V

CC mode

Range

0-3A 0-30A

0-3A 0-30A

Resolution

0.1mA 1mA

0.1mA 1mA

Accuracy

0.03%+0.05%FS

0.03%+0.05%FS

CV mode

Range

0.1-19.999V 0.1-150V

0.1-19.999V 0.1-150V

Resolution

1mA 10mA

1mA 10mA

Accuracy

0.03%+0.02%FS

0.03%+0.02%FS

CR mode

Range

0.03Ω-10KΩ 0.03Ω-5KΩ

0.03Ω-10KΩ 0.03Ω-5KΩ

Resolution

16bit

16bit

Accuracy

0.1%+0.1%FS

0.1%+0.1%FS

CW mode

Range

0-150W 0-150W

0-300W 0-300W

Resolution

1mW 10mW

1mW 10mW

Accuracy

0.1%+0.1%FS

0.1%+0.1%FS

Vmeasurement

Voltage

1-19.999V 1-150V

1-19.999V 1-150V

Resolution

0.1mV 1mV

0.1mV 1mV

Accuracy

0.015%+0.02%FS

0.015%+0.02%FS

I measurement

Current

0-3A 0-30A

0-3A 0-30A

Resolution

0.01mA 0.1mA

0.01mA 0.1mA

Accuracy

0.03%+0.05%FS

0.03%+0.05%FS

Wmeasurement

Watt

100W 150W

100W 300W

Resolution

1mW 10mW

1mW 10mW

Accuracy

0.1%+0.1%FS



Specifications

Model

ATZ9711

ATZ9712

Input raiting

Power

150W

300W

Current

0-30A

0-30A

Voltage

0-150V

0-150V

CC mode

Range

0-3A 0-30A

0-3A 0-30A

Resolution

0.1mA 1mA

0.1mA 1mA

Accuracy

0.03%+0.05%FS

0.03%+0.05%FS

CV mode

Range

0.1-19.999V 0.1-150V

0.1-19.999V 0.1-150V

Resolution

1mA 10mA

1mA 10mA

Accuracy

0.03%+0.02%FS

0.03%+0.02%FS

CR mode

Range

0.03Ω-10KΩ 0.03Ω-5KΩ

0.03Ω-10KΩ 0.03Ω-5KΩ

Resolution

16bit

16bit

Accuracy

0.1%+0.1%FS

0.1%+0.1%FS

CW mode

Range

0-150W 0-150W

0-300W 0-300W

Resolution

1mW 10mW

1mW 10mW

Accuracy

0.1%+0.1%FS

0.1%+0.1%FS

Vmeasurement

Voltage

1-19.999V 1-150V

1-19.999V 1-150V

Resolution

0.1mV 1mV

0.1mV 1mV

Accuracy

0.015%+0.02%FS

0.015%+0.02%FS

I measurement

Current

0-3A 0-30A

0-3A 0-30A

Resolution

0.01mA 0.1mA

0.01mA 0.1mA

Accuracy

0.03%+0.05%FS

0.03%+0.05%FS

Wmeasurement

Watt

100W 150W

100W 300W

Resolution

1mW 10mW

1mW 10mW

Accuracy

0.1%+0.1%FS

0.1%+0.1%FS
